C60800 is a specific type of copper alloy known as "Aluminum Bronze."

C60800 copper alloy, commonly known as Aluminum Bronze, has a specific chemical composition that contributes to its unique properties. Here is the typical chemical composition of C60800:

Copper (Cu): Approximately 91.0% to 93.0%

Aluminum (Al): Approximately 6.0% to 8.0%

Iron (Fe): Maximum of 1.5%

Nickel (Ni): Maximum of 1.0%

Manganese (Mn): Maximum of 1.0%

Silicon (Si): Maximum of 0.1%

Lead (Pb): Maximum of 0.05%

Phosphorus (P): Maximum of 0.05%

Zinc (Zn): Maximum of 0.5%

These percentages may vary slightly depending on the specific manufacturer or standard, but they give a good general idea of the composition of C60800 copper alloy.

Key points about the chemical composition:

Copper (Cu): This is the primary element in C60800, providing the base for the alloy's properties, such as electrical conductivity and corrosion resistance.

Aluminum (Al): Aluminum is the main alloying element in C60800, which contributes significantly to its strength, hardness, and corrosion resistance, particularly in marine environments.

Iron (Fe) and Nickel (Ni): These elements are present in limited amounts to enhance specific properties, such as strength and toughness.

Manganese (Mn), Silicon (Si), Lead (Pb), Phosphorus (P), and Zinc (Zn): These elements are present in trace amounts to control impurities and improve various aspects of the alloy, including machinability, casting properties, and overall performance.

C60800, also known as Aluminum Bronze, exhibits several distinctive features that make it a valuable material in various industrial and marine applications:

High Strength: C60800 offers excellent mechanical properties, including high tensile strength and hardness. This makes it suitable for applications where strength and durability are critical.

Corrosion Resistance: One of the standout features of C60800 is its exceptional corrosion resistance, particularly in marine environments. It is highly resistant to corrosion from seawater, brine solutions, and many chemicals, making it ideal for components exposed to aggressive environments.

Wear Resistance: The alloy possesses good wear resistance, making it suitable for components subjected to friction and wear. This property contributes to its longevity and reliability in applications where mechanical stress is prevalent.

High Temperature Resistance: C60800 exhibits good resistance to high temperatures and thermal expansion. This property is beneficial in applications where the material is exposed to elevated temperatures or rapid temperature changes.

Machinability: Despite its high strength, C60800 maintains good machinability. It can be easily machined into complex shapes and precision components, which is advantageous in manufacturing processes.

Non-Sparking and Non-Magnetic: C60800 is non-sparking and non-magnetic, making it suitable for applications where these properties are required, such as in environments with flammable gases or where electromagnetic interference (EMI) must be minimized.

Aesthetic Appeal: Aluminum Bronze has an attractive golden color, which can enhance the aesthetic appeal of components in architectural and decorative applications.

Applications:

1. Marine: Commonly used for marine applications including propeller shafts, valve seats, pumps, and underwater equipment due to its corrosion resistance.

2. Industrial: Utilized in industrial sectors such as oil and gas, chemical processing, and aerospace for valves, fittings, heat exchangers, and other critical components.

3. Aerospace and Defense: Its combination of strength and corrosion resistance makes it suitable for aerospace and defense applications where reliability in harsh conditions is essential.
